Magnetic handling

Handling magnets are the solution for quickly and safely picking up, transporting, lifting or securing your steel products
Magnetic product handling reduces both the duration and number of operations. Ideal for automating your processes.

On this site, you will find various magnet systems for the metal, automotive and robotic industries.

  • Engineering, production & service
  • According to your requirements
  • In-house test centre
  • 60 years of experience
  • Quality and reliability
Magnetic gripper steel perforated plate red

Lifting magnets & handling magnets

Lifting magnets and handling magnets are suitable for picking up, hoisting, placing or positioning steel - ferromagnetic - objects.

  • For robot, tackle or manually
  • Pneumatically, electrical or manually switchable
  • Lifting power: up to 15,000 kg
  • With permanent magnets or electromagnets
  • Suitable for all shapes and sizes
Switchable sheet separator

Sheet separators

Magnetic sheet separators separate sticky or oiled steel sheets and prevent more than one sheet being picked up at the same time. Very important for fully automated processes.

  • Spread stacked sheets
  • Switchable or permanent magnetic
  • For sheets up to 4 mm thick
  • Quick and efficient
  • With permanent magnets
Palletizing magnet for tins and cans

Magnetic palletizers

Suitable for packing and unpacking tins, aerosols, cans and jars with screw lids. The solution for filling or emptying pallet layers in one movement.

  • Pneumatically switchable
  • For cans, aerosols, drums, etc.
  • Max. dimensions: 1420x1400 mm
  • With permanent magnets
Magnetic aligner for nails and screws

Aligners

Aligners are suitable for aligning elongated steel objects. This enables the compact packaging of nails, screws and threads, for example.

  • For items such as nails and screws
  • For packages up to 35 kg
  • Electromagnet with air cooling
  • Electric control
Shuttering magnet

Shuttering magnets

These magnet clamps are suitable for securing or fixing steel moulds in the concrete industry.

  • Permanent magnetic
  • Max. holding force: 9000 N
  • Compact design
Magsquare welding clamping magnet

Switchable welding magnets

Switchable welding magnets are ideal for quickly temporarily holding steel workpieces in any desired position.

  • Switching: manual
  • Max. holding force: 4500 N
  • Magnet produces magnetic field on 3 sides
Magnetic coveyor rails and rollers for tins and cans

Magnets for transporting cans

With various magnetic rails and rollers you can build your own transport lines for empty or filled cans, aerosols, crown caps or screw lids.

  • Separate magnetic components
  • Can be built into conveyor lines
  • For cans, aerosols, drums, etc.
  • Also for wet conditions
Timing belt magnetic sheet conveyor

Timing belt magnetic conveyors

Timing belts transport steel sheets - up to 5 mm thick - to and from processing machines. Very accurate and fast.

  • For sheets up to 5 mm thick
  • Capable of exact positioning, no slip
  • Quick start/stop
  • Easily integrated
  • With permanent magnets or electromagnets
Magnetic conveyor rollers for sheets

Magnetic conveyor rollers for sheets

Magnet rollers are designed to transport steel sheets to and from processing machines. They maintain their strength for life and are easy to install.

  • For thick and thin sheets
  • Easy to install
  • Maintenance-free
  • Permanent magnetic
  • With ferrite magnets
Magnetic slide conveyor type Swan neck for transporting steel parts

Magnetic slide conveyors

Magnetic slide conveyors transport small, sharp metal parts. They contain no external moving parts, making them very suitable for oiled products such as punch scrap.

  • Sealed construction
  • Require little maintenance, no belt wear
  • Gentle or steep transport angle (up to 60°)
  • Max. elevation height: 12 m
Goudsmit magnetic feed conveyor with nails

Magnetic feed conveyors

Magnetic feed conveyors provide steeply upward sloping transport of steel parts, such as nails, screws or other long steel parts, in the packaging industry.

  • For metered infeed/discharge
  • Steep angle of rise of 60°
  • Max. belt width: 750 mm
  • Max. elevation height: 5 m
